Srisailam Reservoir — Attraction in Andhra Pradesh

The Srisailam Reservoir, also known as the Srisailam Dam, is a major water reservoir located in the Indian states of Andhra Pradesh and Telangana. It is built across the Krishna River and serves as one of the key water storage facilities in the region.

Key features of the Srisailam Reservoir:

Location: The dam is situated near the town of Srisailam, which is famous for the ancient Hindu temple dedicated to Lord Shiva, known as the Srisailam Mallikarjuna Temple.

Purpose: The primary purpose of the Srisailam Reservoir is to store water for irrigation, drinking water supply, and hydroelectric power generation. It plays a crucial role in the agricultural activities of the region.

Hydroelectric Power: The dam also has a hydroelectric power station with a capacity of generating electricity. The power station utilizes the flow of water to produce electricity, contributing to the energy needs of the area.

Joint Project: The construction of the Srisailam Reservoir was a joint venture between the states of Andhra Pradesh and Telangana, as the dam's location lies on the border of these two states.

Catchment Area: The reservoir's catchment area extends to parts of Karnataka and Maharashtra, with several tributaries feeding into the Krishna River, which is then stored in the dam.

Tourism: Besides its functional aspects, the Srisailam Reservoir and the surrounding landscapes offer picturesque views, attracting tourists and nature enthusiasts.

The Srisailam Reservoir is an essential infrastructure project that provides water for irrigation and other purposes, contributing significantly to the region's agricultural development and...

The Srisailam Dam is constructed across the Krishna River in Kurnool district, Andhra Pradesh near Srisailam temple town and is the 2nd largest capacity working hydroelectric station in the country.

The dam was constructed in a deep gorge in the Nallamala Hills in between Kurnool and Mahabubnagar districts, 300 m (980 ft) above sea level. It is 512 m (1,680 ft) long, 145 metres (476 ft) maximum height and has 12 radial crest gates. It has a reservoir of 616 square kilometres (238 sq mi). Project has an estimated live capacity to hold 178.74 Tmcft at its full reservoir level of 885 feet (270 m) MSL. The minimum draw down level (MDDL) of the reservoir is at 705 feet (215 m) MSL from its river sluice gates and corresponding dead storage is 3.42 Tmcft.The left bank underground power station houses 6 × 150 megawatts (200,000 hp) reversible Francis-pump turbines for pumped-storage operation and the right bank semi under ground power station houses 7 × 110 megawatts (150,000 hp) Francis-turbine generators.

Tail pond dam /weir located 14 km downstream of Srisailam dam is under advanced stage of construction to hold the water released by the hydro turbines and later pump back into the Srisailam reservoir by operating the turbines in pump mode.The weir portion got breached in November 2015 unable to withstand the normal water release from the hydro power stations.Tail pond weir was completed during the year 2017 and pumping mode operation is being done even the downstream Nagarjuna Sagar reservoir water level is below 531.5 feet (162 m) MSL. The tail pond has nearly 1 tmcft live...

The dam was constructed in a deep gorge in the Nallamala Hills in between Nandyal and Nagarkurnool districts, 300 m (980 ft) above sea level. It is 512 m (1,680 ft) long, 145 metres (476 ft) maximum height and has 12 radial crest gates. It has a reservoir of 616 square kilometres (238 sq mi). Project has an estimated live capacity to hold 178.74 Tmcft at its full reservoir level of 885 feet (270 m) MSL. It's gross storage capacity is 6.116 cubic kms (216 tmc ft). The minimum draw down level (MDDL) of the reservoir is at 705 feet (215 m) MSL from its river sluice gates and corresponding dead storage is 3.42 Tmcft.[4] The left bank underground power station houses 6 × 150 megawatts (200,000 hp) reversible Francis-pump turbines for pumped-storage operation (each Turbine can pump 200 cumecs) and the right bank semi under ground power station houses 7 × 110 megawatts (150,000 hp) Francis-turbine generators.

Tail pond dam/weir located 14 km downstream of Srisailam dam is under advanced stage of construction to hold the water released by the hydro turbines and later pump back into the Srisailam reservoir by operating the turbines in pump mode.[5] The weir portion got breached in November 2015 unable to withstand the normal water release from the hydro power stations.[6] Tail pond weir was completed during the year 2017 and pumping mode operation is being done even when the downstream Nagarjuna Sagar reservoir water level is below 531.5 feet (162 m) MSL. The tail pond has nearly 1 tmcft live...
